HAP-1000XP/HAP-2000XP Fully Automatic Multi-point pressure & central pressure Metallographic Grinding and Polishing Machine
HAP-1000XP//HAP-2000XP Automatic Metallographic Grinding and Polishing machine
- Single sample was loaded independently
- Center loading of sample tray
Six samples can be loaded at one time, and a four-channel automatic drip device (optional) can be configured to complete the grinding and polishing process automatically.
- Single and double grinding disc, support:
- Single sample was loaded independently
- Sample plate center loading, fixed six samples at a time, complete the whole grinding and polishing process, to make sure the surface of each sample is smooth and polished
- Polishing plate and sample plate: set and run speed, polishing time, rotating direction, water valve closing and other polishing parameters, and automatically save, easy to switch;
- Touch screen interface: easy to set grinding parameters, intuitive state display, simple operation;
- Grinding plate and sample plate rotate continuously variable speed, rotation direction can be changed;
- Three working modes:
- Automatic mode:
30 sets of processes (processes) can be set and called according to the sample materials or the habits of users, and each set of processes can contain 10 steps of process parameters (parameters of each process for a certain step of grinding or polishing process: rotation speed of grinding disc and grinding head, grinding and polishing time......)
- Single process mode:
According to each grinding and polishing process, 30 kinds of process parameters can be set and called: the rotation speed of the grinding plate and the grinding head, grinding and polishing time, water on and off......
- Manual mode:
Perform an independent operation on a function of the device
- Equipped with four-channel automatic drip device (optional):
- The main machine of the polishing machine controls the four-channel dropper, and the dropper variety and speed are all given instructions by the polishing machine
- There are three working modes: manual, on-line and automatic
- Connect the polishing machine with the polishing machine and drop liquid according to the polishing parameters set by the polishing machine;Each mode can be set independently: drip speed, drip time
- U disk storage of 300 processes, can be imported and exported;
- Grinding head electromagnetic automatic locking, instead of manual grinding head locking spanner, more convenient;
- Easily replace the magnetic anti-stick plate, can complete all kinds of sample rough, fine grinding and rough, fine polishing and other processes, a plate is equivalent to N plates;
- Switch between Chinese and English interface.
- Optional Mobile remote control operation (optional).
- Technical parameters:
| Item | HAP-1000XP | HAP-2000XP |
| Station | Single disc | Double disc |
| Working disc diameter | Standard with φ254mm (optional φ230mm/φ203mm, customized φ304mm) with magnetic conversion disk system |
| Rotate speed | 50-1000 RPM reverse rotation can be switched |
| Sample plate speed | 30-200 RPM reverse rotation can be switched |
| Manual mode | You can select 30 groups of parameters, each set and invoked separately |
| Automatic mode | 30 sets of process (process), each set of process contains 10 steps of process parameters (from process 1 to process 10 automatically, each step has an independent set of parameters) |
| Sample holder | 30mm can be 6 holes (optional 20mm 6 holes, 40mm, 50mm 3 holes, others can be customized) |
| Grinding head locking mode | Electromagnetic automatic lock |
| Drip device (optional) | 4 channel Grinding and polishing machine controls the drip operation |
| Working air source pressure | More than 0.6MPa |
| Motor power | 0.75 Kw |
| Power supply | AC220V, 50/60Hz, 2KW |
| Overall dimensions | 760 x 470 x 700mm | 760 x 730 x 700mm |
| Weight | 63kg | 74kg |
| | | | |
| Item | Quantity (Single disk/double disk) | Item | Quantity (Single disk/double disk) |
| Central loading mechanism | 1 set | Magnetic disk (254mm) | 1/2 pcs |
| Diamond suspension polishing fluid 1 micron, 6 micron 200 ml | Each 1 bottle | Anti-sticking plate | 2 pcs |
| 180#, 600#, 1000# sand paper with backadhesive 254mm(available 250 mm) | Each 2 pcs | Polishing cloth (with adhesive, 250mm) Velvet, canvas | 1 Each |
| Inlet & outlet pipe and accessories | 1 set | Product instruction manual, product certificate | 1 Each |
- Four channel automatic dripper
- Mobile terminal remote control operation module
- Air pump
- Huawei FLAT-panel M6 10.8in Kirin 980 4GB+64GB WiFi
- Common consumables:
| MAGNOMET | - anti-sticky disc 5peices/box
- diameter:Φ254mm
- Surface coating with Special anti-sticky layer, can attach the sticky paper and polishing cloth directly, and easily replace without sticky mark.
- Can be reuse
- Can be replace the BUEHLER and STRUERS same production
|
| GSC250A | - 100peices /package
- material: black carborundum
- sand size:P80# 120# 180＃ 320＃ 600＃ 800＃ 1000＃ 1200＃ 1500＃ 2000＃
- size:Φ250mm
- waterproof and one side sticky, can be attached on the grinding plate directly
|
| FT250A | - polish cloth 10peices/package
- velvet fabric(long floss) / canvas(short floss)/ Woolen cloth(short floss)/ silk cloth(no floss)
- Φ250mm
- one side sticky, can be attached directly on the grinding plate
|
| DSU | - Diamond grinding and polishing liquid,500ml/bottle
- Diamond suspending in the liquid, can be dropped automatically or watering pot, Uniformly distribution
size:0.25, 0.5, 1, 1.5, 2.5, 3, 3.5, 5, 6, 7, 9, 10, 14, 15, 20, 28, 40micron, for different material |
Four-channel automatic drip (optional)
Optional grinding quantity control fixture rotation is 0.02mm.
